Name: FM-TS Sleeve Type 7 colors paper bags flexographic printing machine sleeve printing machine
Brand: Wenzhou Fengming Machinery Co., Ltd.
SKU: FM-TS
Price: 225,000.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Highlight:

sleeve printing machine flexographic

paper bags printing machine

7 colors sleeve printing machine

Basic Infomation

Place of Origin: China

Brand Name: Fengming

Certification: CE

Model Number: FM-TS

Payment & Shipping Terms

Packaging Details: Pallet and Wrapping Film

Delivery Time: 60 days

Payment Terms: T/T, L/C

Supply Ability: 5 Sets / Month

Gallery

FM-TS Sleeve Type 7 colors paper bags flexographic printing machine sleeve printing machine

Product Description

FM-TS Sleeve Type 7 colors paper bags flexographic printing machine sleeve printing machine 0

Product Description

SLEEVE TYPE FLEXOGRAPHIC PRINTING MACHINE

This state-of-the-art sleeve-type flexographic printing machine combines rapid plate changeover technology with full servo drive control for unmatched production flexibility and efficiency.

Featuring an innovative petal-shaped structure that maintains stable printing pressure at high speeds, this advanced flexo press eliminates traditional gear pitch limitations, accommodating unlimited printing repeat lengths for maximum versatility.

The system offers dual ink compatibility, supporting both water-based ink and UV ink technologies for diverse substrate and application requirements. Integrated digital inspection, automatic registration, and pre-registration systems significantly reduce operator dependency while dramatically improving print quality and production yield rates.

Ideal for packaging converters, label manufacturers, and flexible packaging producers seeking a high-performance, digitally-enhanced flexographic printing solution that delivers superior quality, faster changeovers, and broader material adaptability for today's demanding short-run and variable production environments.

Specification

Max.Web Width	870mm	1020mm	1270mm	1370mm
Max.Printing Width	850mm	1000mm	1250mm	1350mm
Pringting Repeat	350-1100mm	350-1100mm	350-1100mm	350-1100mm
Max.Unwinder Diameter	1524mm	1524mm	1524mm	1524mm
Max.Rewinder Diameter	1524mm	1524mm	1524mm	1524mm
Max Speed	300m/min	300m/min	300m/min	300m/min

Drying Mode	a.Hot Air Drying b.IR Drying c.UV LED Drying
Ink Used	a.Water-based ink b.UV ink
Power Requirement	380V 3PH 50Hz
Substrate	Copy paper, 80-350gsm At Paper, Aluminium-foil Paper, BOPP PET, Paper Board, Kraft Paper, Coating paper, Composting paper
Applicable Material Weight	80gsm-350gsm
Thickness Of Plate	1.7mm
Thickness Of Self Adhesive	0.38mm/0.5mm
Rack Of Machine	Whole Metal Alloy Casting Wall Panel
Accuracy Of Registration	a.When the machine is runing at a unifrim speed,the printing accuracyis+/-0.1mm b.The speed accelerate from 10m/min to 180m/min,set theprintingaccuracyis+/-0.12mm,and the speed slows downfrom 180m/minto 10m/min,the printing accuracy is+/-0.12mm
The Range Of Tension Controler	(40-110)kg
The Range Of Tension Accuracy	+/-0.5kg
Note: as the products are developing day by day, the technical data are subject to change without notice.

Functional Advantages

SLEEVE-TYPE PRINTING PLATE ROLLER

Convenient and quick plate changing; orders of varying lengths are not limited.

PETAL-SHAPED STRUCTURE

Stable printing pressure, with better stability at high speeds.

FULL SERVO DRIVE

No tooth pitch limitation on printing repeat length, making the machine more versatile.

COMPATIBLE WITH BOTH WATER-BASED AND UV INKS

Water-based inks or UV inkjet printing or stencil printing can be selected according to the requirements of the printed products, broadening the adaptability to printed patterns and materials.

DIGITALIZATION

Digital full inspection, digital registration, and pre-registration reduce the machine's dependence on human operators and increase yield.

Core Applications

FLEXIBLE PACKAGING CONVERSION
Perfect for flexible packaging converters producing food packaging films, snack pouches, coffee bags, and multilayer laminated structures. The sleeve system's quick changeover capability and unlimited repeat flexibility make it ideal for high-mix production environments requiring frequent job changes, multiple SKUs, and diverse substrate handling for food, beverage, and consumer goods packaging.

LABEL & FILM BAGS POUCHES PRINTING
Essential equipment for label manufacturers to make pressure-sensitive labels, wrap-around labels, product identification tags, and film bags. The digital registration system ensures precise color alignment critical for brand-consistent graphics, while the servo drive accommodates varying label lengths without tooling limitations, supporting both standard and custom label dimensions.

PAPER CUPS PAPER BOWLS PAPER BOXES PRINTING
Widely used in paper cups paper bowls factories,for high quality eco-friendly paper cups paper bowls paper boxes printing production
fast printing speed,automatic color registration. greatly improve paper cups paper bowls factory printing quality,productivity and profitability.

PAPER & SPECIALTY BAGS MANUFACTURING
Optimized for paper bags factories to make retail shopping bags, gift bags,food service bags, and promotional packaging. The quick plate-changing sleeve system enables efficient printing production of multiple bags in different designs and sizes within single production shift, while dual ink options provide flexibility for decorative printing and functional barrier printing effects.

PHARMACEUTICAL & MEDICAL PACKAGING
Suitable for pharmaceutical packaging converters producing blister packaging, medical device pouches, drug labels, and compliance packaging materials. The digital inspection system ensures 100% quality verification meeting stringent pharmaceutical standards, while UV ink options provide tamper-evident and durable printing for regulated medical applications.

FAQ

Q1: How about the after-service?
A: We have a strong team, especially for after-sales service. We can arrange for engineers to do service for you.

Q2: Are you a factory or a trading company?
A: Professional manufacturer of flexo printing machines. We are definitely a factory.

Q3: Where is your factory located? How can I visit there?
A: Our factory is located in Pingyang, Wenzhou City, Zhejiang Province, China, near the Wenzhou airport. You can fly to Wenzhou Airport directly.

Q4: How does your factory perform regarding quality control?
A:Quality is apriority. We always attach great importance to quality control from the very beginning.

Q5: Why choose Fengming Machinery?
A: Our qualified products and services have enabled us to expand our market from China to more than 40 countries. We are confident that you will be satisfied with our machines.

Welcome to visit Fengming Machinery!
