Multifunctional Paper Cup Flexo Printing Machine Custom 6 Colour Flexo Printing Machine

1
MOQ
USD120000-190000/Set
Price
Multifunctional Paper Cup Flexo Printing Machine Custom 6 Colour Flexo Printing Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Model NO.: FM-CS
Type: Flexo
Embossing Structure: Rotary Letterpress
Structure: Unit Type
Application: Flexible Packaging Printing
Automatic Grade: Automatic
Printing Speed: 200m/min
Max. Web Width: 1370mm
Max. Printing Width: 1350mm
Printing Repeat Length: 300-1200mm
Max.Unwinder Diameter / Rewinder: 1524mm
Gearing: 1/8cp
Diameter Of Web Roller: 100mm
Drying Mode: Hot Air Drying & IR Drying / UV Drying
Printing Material: 60-350GSM Paper Roll
Transport Package: Wooden Pallet With Film Package
Specification: CE ISO9001
Trademark: Fengming
Origin: China
HS Code: 8443160090
Supply Ability: 5 Sets / Month
After-sales Service: After-Sales Service Is Available Overseas
Warranty: 1 Year
Printing Page: Single Faced
Printing Color: 8 Colors
Anilox Roller: Ceramic Anilox Roller
Dryer: UV& IR
Customization: Available | Customized Request
Highlight:

Multifunctional Paper Cup Flexo Printing Machine

,

Custom Paper Cup Flexo Printing Machine

,

Custom 6 Colour Flexo Printing Machine
Basic Infomation
Place of Origin: CHINA
Brand Name: FENGMING
Certification: CE
Model Number: FM-CS1020
Payment & Shipping Terms
Packaging Details: wooden pallet
Delivery Time: 30 working days
Payment Terms: T/T,L/C
Supply Ability: 15 sets
Product Description

FM-CS1320 Petal type paper bags printing machine High Speed 6 Color Flexo Printing Machine for 60-350GSM Paper Roll

Multifunctional Paper Cup Flexo Printing Machine Custom 6 Colour Flexo Printing Machine 0
FM-CS1020-1350 Flexographic Printing Machine (Petal Type)

  1. Petal type plate mounting, anilox and cylinder with quick change structure.
  2. Printing unit easy operation, cylinder and anilox pressing once successfuly.
  3. Plate full servo shaftless transmission, automatically pre-print, time saving & material saving.
  4. Registering remains the same during lifting process.
  5. Register position automatic memory function.Multifunctional Paper Cup Flexo Printing Machine Custom 6 Colour Flexo Printing Machine 1
Multifunctional Paper Cup Flexo Printing Machine Custom 6 Colour Flexo Printing Machine 2 Multifunctional Paper Cup Flexo Printing Machine Custom 6 Colour Flexo Printing Machine 3
Multifunctional Paper Cup Flexo Printing Machine Custom 6 Colour Flexo Printing Machine 4
Applications:
Suitable for eco-friendly packaging, such as the paper bag used for food and healthcare industry, paper box, paper cup, the pre-printing carton of paper bag, bag courier, milk carton medicine use.
Paper Used:
Kraft paper, paperboard, coated paper, liner paper, laminated paper, multilayer composite paper, carton board materials ect.
Technical Parameters:
Specification 1020 1300 1350
Max. Web Width 1020mm 1300mm 1370mm
Max. Printing Width 1000mm 1270mm 1350mm
Printing Repeat 300-1200mm 300-1200mm 300-1200mm
Max.Unwinder Diameter 1524mm 1524mm 1524mm
Max.Rewinder Diameter 1524mm 1524mm 1524mm
Gearing 1/8cp 1/8cp 1/8cp
Max Printing Speed 160-200m/min 160-200m/min 160-200m/min
Diameter of web roller 100mm 100mm 100mm
Drying mode Hot Air Drying/IR Drying/ UV Drying
Printing Material 60-300gsm paper roll

About us
Multifunctional Paper Cup Flexo Printing Machine Custom 6 Colour Flexo Printing Machine 5 Established in 2006, Wenzhou Fengming Machine Co.,Ltd is a professional manufacturer and exporter of Flexo Printing Machine and Wax Coating Machine. We are located in the urban distric of Pingyang, economically developed city on the bank of East China of Zhejiang, Covering an area of 9300 square meters, we now have over 120 employees.With Superior quality, satisfying after sales services, we have got many orders from different customers all over the world. We have exported our machines to more than 30 countries such as Russia, India, Turkey, Thailand, Egypt, etc. And the feedback we get from customers are they feel satisfied with our machines. We always regards "today's quality is tomorrow's market and users are supreme" as aim, and has gained reliance and praise from customers Welcome to visit our factory and to order from us!
Multifunctional Paper Cup Flexo Printing Machine Custom 6 Colour Flexo Printing Machine 6
Multifunctional Paper Cup Flexo Printing Machine Custom 6 Colour Flexo Printing Machine 7
Multifunctional Paper Cup Flexo Printing Machine Custom 6 Colour Flexo Printing Machine 8
Multifunctional Paper Cup Flexo Printing Machine Custom 6 Colour Flexo Printing Machine 9
