Sleeve Type Flexo Printing Machine for Paper Cup Carton Bag Package 1000mm Width PLC Control 150m/min Speed

It is controlled centrally by PLC system and generally consists of unwinding section, infeed section,printing section, drying section, outfeed section, rewinding section and control section.This machine is an ideal machine for printing paper cup, carton, paper bag, paper package, and so on

Main Technical Parameter:

Specification

39.5"(1000)

Max.Web Width

1020mm

Max.printing width

1000mm

Max.Die-cutting width

1000mm

Printing Repeat length

286--1200mm

Die-cutting Repeat length

286--1200mm

Max.Unwinder Diameter

1524mm

Max.Rewinder Diameter

1524mm

Gearing

1/8cp

Max. mechanical speed

150m/min

Max printing speed

120m/min

Diameter of web roller

100mm

Base motor power

11KW

Drying mode

a. WARM DRYING b. IR DRYING

Applicable Ink

a. Water-based ink b. UV ink

Power Requirement

380V 3PH 50Hz

Printing Material

Light weight coated paper, carton board materials, kraft paper, chrome paper, PVC wall paper, laminated paper, white cardboard paper, aluminium-foil paper
